DroneScoutDroneScout Bridge ds110
Your phone misses most Remote ID drones. The ds110 receives them on every Remote ID transport, on 2.4 and 5 GHz, and passes them on to any iPhone or Android phone — up to 2 km away.
€149 excl. VAT · worldwide shipping · quantity discounts from 3 units
Why your phone needs it
Drones broadcast Remote ID over several radio transports, and phones receive only some of them:
- An iPhone can't receive Bluetooth Long Range S8, and iOS doesn't let apps scan for Wi-Fi Beacons — which is what most drones, including DJI, use. Without Bridge, an iPhone sees only Bluetooth Legacy broadcasts. See the FAQ.
- Many Android phones lack Bluetooth Long Range S8 or receive it badly, and Android throttles Wi-Fi scanning to about twice a minute. See the FAQ.
- Some drones, such as Skydio, broadcast only on 5 GHz, which no phone app can receive.
How it works
The ds110 listens on Bluetooth Legacy, Bluetooth Long Range S8, Wi-Fi Beacon and Wi-Fi NaN on 2.4 GHz, and on Wi-Fi at 5 and 5.8 GHz. Everything it receives, it rebroadcasts as plain Bluetooth Legacy, which every phone and tablet receives reliably.
- No pairing. The relay uses ordinary, connectionless Bluetooth: switch the ds110 on and the drones appear in the app.
- Works with any Remote ID app that receives Bluetooth — the free DroneScout pro app or your favourite one.
- Powered by USB-C, from your phone or a USB power bank, or through its JST-SH connector.
- Range up to 2 km with the included 5 dBi antenna, which you can swap for another antenna. The actual range depends on the drone, the terrain and interference.
Also for drones and integrators
- Detect and avoid: the ds110 can output every detected drone as MAVLink messages (ADSB_VEHICLE or OPENDRONEID message packs) on its UART connector, for DAA on your own drone or aircraft. Example Python and C code is available.
- Compliance checks: it runs 10 basic checks on a drone's Remote ID broadcast — handy to test your own drone.
Specifications
| ds110 | |
|---|---|
| Receives | Bluetooth 2.4 GHz, Wi-Fi 2.4 GHz, Wi-Fi 5 and 5.8 GHz |
| Relays as | Bluetooth 4 (Legacy) |
| Antenna | 5 dBi, RP-SMA connector, replaceable |
| Detection range | Up to 2 km |
| Power | USB-C, or JST-SH 4-pin |
| Average power use | 450 mW |
| Connectivity | USB-C (serial), 2× JST-SH 4-pin (IN and OUT) |
| Operating temperature | −40 °C to +85 °C |
| Size | 71 × 24 × 13 mm without antenna; antenna 157 mm |
| Weight | 32 g |
Full details are in the manual (PDF).
Other models
The ds111 is smaller and cheaper, with an internal antenna and up to 1 km range. The ds100 receives 2.4 GHz only. PCB versions without enclosure are available for integration into your own products. Compare all models at dronescout.co/bridge.
